Mô tả
Đầu đo IMADA eLM-500N
[eZ-Connect series load cell specification]
Model eLM series eLC series eDD2 series
Capacity Refer the model list Refer the model list Refer the model list
Accuracy
10N~10kN：±2.0%F.S. or less
20kN：±3.5%F.S. or less +/-0.5%F.S. or less +/-0.5%F.S. or less
Safe overload
rating
10N~2000N：200%R.O
5000N~20kN：120%R.O
150% 120%
Working
environment
(allowable
temperature)
10N~2000N：
0~50 degree Celsius
(-10~60 degree Celsius)
5000N~20kN：
-5~50 degree Celsius
(-10~60 degree Celsius)
-10~70 degree Celsius
(-15~80 degree Celsius)
-10~+50 degree Celsius
(-30~+50 degree
Celsius)
Cable 10N~2000N：Approx.2m
5000N~20kN：Approx.3m
Approx.5m Approx.5m
Dimensions Refer to the dimension Refer to the dimension Refer to the dimensio
